PRODUCT DESCRIPTION
A Gate valve with flanged ends is a type of isolation valve commonly used in piping systems to start or stop the flow of a fluid. The flanged ends allow the valve to be bolted between two sections of pipe using standardized flanges, making installation, maintenance, and removal easier in high-pressure and industrial environments.
TECHNICAL SPECIFICATIONS
Size Range | 50 MM to 600 MM (2” To 24”) |
Temperature Range | -40° C to +425° C |
Pressure Rating | Class 150 / 300 / 600 |
Design Standard | As Per API 600 |
Face To Face | As Per ASME B16.10 |
Testing | As per API 598 |
Leakage Class | Class VI |
Operation | Handwheel,Gearbox,Actuated |
End Connection | Flanged end suitable to mount between ASME B16.5 Flanges |
